Designed for the all new 2023 CVO and 2024 Street Glide
Looking for a narrower overall width? At 34" wide, The Patriot Bagger is the handlebar for you. The squared up style of the Patriot gives your motorcycle a custom look to set you apart from the pack. The narrow width is comfortable stance for riders of all styles
Mfg. out of 1.5" diameter 304 ornamental grade stainless steel and CNC mandrel bent
Notched and slotted for internal wiring.
-High Gloss or polished stainless steel. High Gloss black powder coating is from the same supplier used by Harley Davidson
Specs: 34" Tip-Tip with 6.5" pullback. Available in 10", 12" and 14" rise. 16" by special order only
Handlebars are stepped down in specific areas so no modifications are required to the fairing in order to make the 1.5" diameter tubing fit correctly
Stock handlebars are 8"
Can be purchased pre wired (available Jan. '24)
-10" Can be installed with all stock components but will require you to manipulate the stock top side of the clutch cable. It has a hard casing with formed bends to follow the geometry of the stock handlebar. You will need to bend those by hand in order to allow the fairing to go back together properly. You can include the new top side clutch cable if you do not want to manipulate it by hand.
-12" and 14" can be installed with stock brake line and electrical harnesses. The clutch cable will need to be extended with 14" the FBI clutch extension or please select "yes" for the extended clutch cable
